Multiple Generator load sharing, kW and kWAr load sharing, Busbar voltages and frequency
measurements, Dead bus detection, Bara error detection, Load dependent auto start / stop,
Generator synchron aging, Manual Voltage / Frequency adjustment, Automatic adjustment feature
for governor and AVR, Volt / frequency and phase matching, Synchronization indication, Logic
control function for PLC.
Communication interface : USB programming and communication port, J1939 ECU and CanBus
communication, CanOpen multiple communication, Ethernet, RS485.
Inputs : 13 Digital Inputs, 4 Analog Inputs, Magnetic Pickup and Charge Alternator (D + (WL)) Input
Outputs : 9 Transistors + 1 Relay output + 1 Relay Generator Contactor output
Load Current Measurement : 3 Phase Current Transformer Input, 1x Earth Leakage Current
Measurement
Voltage Measurement : 3 phase Generator and Bar
Cos-ɸ Measurement : 3 phase Generator Cos-ɸ measurement
